Rotary Premade Pouch Packing Machine

Rotary premade pouch packing machine:

HUAPACK automatic rotary premade pouch packaging machine is a high-quality packaging machine with fast packaging speed, and can also achieve three-side sealing, four-side sealing bag type flat bags, zipper bags, etc. , solid materials and other packaging requirements, equipped with flexible processing stations, which can automatically Pick bags, open bags, detect, fill, seal and other packaging processes. The bag-feeding model series is an economical and reasonable packaging choice.

Rotary Premade Pouch Packing Machine Features:

1. The whole machine is designed in accordance wit GMP standards and has passed CE certification

2. Full servo control system is adopted for actio execution, which is reliable, fast and accurate.

3. It is equipped with an automatic fault tracking and alarm system, providing real-time display of operating conditions.

4. The machine utilizes a fully servo-controlled system for all actions, ensuring reliable, fast, and accurate execution.

Rotary premade pouch packing machine application range

• 1. Liquids: detergent, wine, soy sauce, vinegar, juice, beverage, ketchup, jam, chili sauce, bean paste.
• 2. Blocks: peanuts, jujubes, potato chips, rice noodles, nuts, candy, chewing gum, pistachios, melon seeds, nuts, pet food, etc.
• 3. Granules: condiments, additives, crystalline seeds, seeds, granulated sugar, soft white sugar, chicken essence, grains, agricultural products.
• 4. Powder: flour, seasoning, milk powder, glucose, chemical seasoning, pesticide, fertilizer

Pouch Sample



Parameters

Model	HC-GD210	HC-GD250	HC-GD300
Pouch Size(mm)	width:90-120mm	width:130-250mm	width:160-300mm
	height: ≤360mm	height: ≤400mm	height: ≤400mm
Station	10 station	8 station	8 station
Packaging Speed	80	70	60
Machine Size	1950*1400*1520	1950*1400*1520	2150*1400*1520
Machine Weight	700kg	700kg	720kg
Power	7kw	7kw	7kw
Air Consumption	5-7Kg/m³,500L/min	5-7Kg/m³,500L/min	5-7Kg/m³,500L/min
